Fetures:
· Smoothly at high speed, solid and durable
· High precision repeatable positioning, strong clmap force, suitable for automatic production
· Especially suitable for clamping atypical work pieces
|
Model |
Wedge core travel(mm) |
Jaw Stroke t (Diamteter) |
Permitted push-pull force(kgf) |
Max. gripping force(kgf) |
Limited rotating speed(r/min) |
Clamping range(mm) |
Inertia(kg.m2) |
Net weight(kg) |
Recommended oil cylinde |
Max. pressure(kgf) |
||
|
4S-06 |
A5 |
20 |
8.5 |
1830 |
5350 |
5250 |
14-165 |
0.05 |
13 |
14 |
SY-100 |
20 |
|
4S-08 |
A5 |
21 |
8.8 |
2550 |
7600 |
4750 |
17-210 |
0.14 |
24 |
28 |
SY-125 |
17 |
|
A6 |
27 |
|||||||||||
|
4S-10 |
A6 |
25 |
8.8 |
2950 |
11000 |
4000 |
22-254 |
0.3 |
35 |
42 |
SY-125 |
20 |
|
A8 |
40 |
|||||||||||
|
Model |
A |
B |
C(H6) |
D |
D1 |
D2 |
E |
E1 |
F |
G |
H |
J |
|||||
|
MAX |
MIN |
||||||||||||||||
|
4S-06 |
A5 |
165 |
74 |
84 |
140 |
104.8 |
82.56 |
116 |
5 |
15 |
21 |
101.5 |
86.5 |
81.5 |
66.6 |
36 |
34 |
|
4S-08 |
A5 |
210 |
85 |
103 |
170 |
133.4 |
82.56 |
140.8 |
5 |
23 |
25 |
127 |
104 |
106 |
83 |
36 |
38 |
|
A6 |
97 |
106.38 |
150 |
17 |
110 |
89 |
|||||||||||
|
4S-10 |
A6 |
254 |
89 |
109 |
220 |
171.4 |
106.38 |
133.4 |
5 |
25 |
34 |
158 |
133 |
133 |
108 |
36 |
45 |
|
A8 |
102 |
139.72 |
190 |
18 |
140 |
115 |
|||||||||||
|
Model |
L1 |
L2 |
M1 |
M2 |
M3 |
N |
P |
R |
S |
T |
|||
|
MAX |
MIN |
||||||||||||
|
4S-06 |
A5 |
14 |
16 |
39 |
M16 x2 |
4-M10 |
3-M6 |
73 |
20 |
18 |
7.5 |
31 |
12 |
|
4S-08 |
A5 |
20 |
17 |
41 |
M20 x 2.5 |
4-M12 |
6-M10 |
95 |
25 |
22.3 |
11.8 |
35 |
14 |
|
A6 |
18 |
3-M6 |
|||||||||||
|
4S-10 |
A6 |
18 |
18 |
46 |
M20 x 2.5 |
4-M16 |
6-M12 |
110 |
30 |
30.8 |
11.3 |
40 |
16 |
|
A8 |
24 |
3-M8 |
|||||||||||
