Project

Model

QY-X614

QY-X618

Processing capability

Workbench size

150×350(6×14")

150×450(6×18")

Maximum grinding length

370mm(14-3/4")

470mm(18-3/4")

Maximum grinding width

160mm(6-1/3")

160mm(6-1/3")

Distance between spindle center and worktbench

400mm(15-3/4")

400mm(15-3/4")

Standard magnet size

150×300mm(6×14")

150×460mm(6×18")

Side-to-side feed

Manual formation

360mm(15")

460mm(19")

Forward feed

Manual feed (per scale)

0.02mm(0.0005")

0.02mm(0.0005")

Manual feed (per revolution)

5mm(1/5")

5mm(1/5")

Up-down feed

Manual feed (per scale)

0.005mm(0.0002")

0.005mm(0.0002")

Manual feed (per revolution)

1mm(0.05")

1mm(0.05")

Grinding wheel

Grinding wheel size (outer diameter×Width×aperture)

180×16×32mm(7×2/3"×1-1/14")

180×16×32mm(7×2/3"×1-1/14")

Speed of spindle(60C/50C)

3600/3000rpm

3600/3000rpm

Motor

Spindle motor(V3 level)

1.5HP 60HZ/3600rpm

1.5HP 60HZ/3600rpm

Weight

Gross weight(approximate)

690kgs(1518lbs)

850kgs(1870lbs)
