XD11 rotary electronic controlled magnetic chuck

ASK for quote

Detail

Features

·Suitable for grinding, iron cutting, wire cutting, sparking, etc.
·High rigidity, high precision, small thermal deformation
·No manpower required, easy to use
·Suction up to 100 N/cm2
·Pole pitch：22mm, customized
·Angle adjustable: ± 90°
Electronic controller（optional）

If you don't have the control system to control the working state of this electromagnetic chuck, our controller is also a good choice.
With AC 0-380V, suitable for all kinds of situation.

Magnetic chuck VS traditional clamping
Compared with traditional clamping, there are a lot of advantages for magnetic chuck
Read more Different magnet types There are three types of magnet, permanent magnetic chuck, electromagnetic chuck, electropermanent magnetic chuck, each one has their advantages.
Read more

Specifications
Applications
Accessories

Model	Dimensions (MM)											Overall Lengh L2	Overall Height H2	Voltage (V)	Current (A)	Power (W)	Net weight (KG)
Model	B1	L1	Le	H1	Polar distance	B2	G	h1	h2	P1	P2	Overall Lengh L2	Overall Height H2	Voltage (V)	Current (A)	Power (W)	Net weight (KG)
XD11-100*250	100	250	211	95	10(2+8)	100	14	91	18	50	38	380	145	110	0.3	33	21
XD11-120*300	120	300	240	95	14(2+12)	100	14	91	18	50	38	430	145	110	0.44	48.4	29
XD11-125*250	125	250	211	95	14(2+12)	100	14	91	18	50	38	380	145	110	0.32	35.2	25
XD11-150*300	150	300	240	95	14(2+12)	100	14	91	18	50	38	430	145	110	0.4	44	37
XD11-150*350	150	350	296	95	14(2+12)	100	14	91	18	50	38	480	145	110	0.42	46.2	41
XD11-150*450	150	450	408	95	14(2+12)	100	14	91	18	60	38	600	145	110	0.5	55	51
XD11-200*500	200	500	452	95	14(2+12)	100	16	120	20	60	43	650	170	110	0.9	122	76
XD11-200*600	200	600	560	95	14(2+12)	100	16	120	20	60	43	750	170	110	1.1	121	89
XD11-300*600	300	600	560	95	14(2+16)	120	16	120	20	80	48	790	170	110	1.4	154	106
XD11-300*680	300	680	620	95	14(2+16)	120	16	120	20	80	48	870	170	110	1.45	159.5	120
XD11-300*800	300	800	740	95	14(2+16)	120	16	120	20	80	48	960	170	110	1.84	202.4	155
Note: Other specifications can be customized ,please call for further information.
